Draughtsman Mechanic

Draughtsman Machanic trade under CTS is one of the popular courses delivered nationwide through network of ITIs.

The course is of two years duration. It maininly consist of Domain area and Core area.

The Domain area(Trade Theory & Practical) imparts professiomal skills and knowledge,while Core area(Workshop Calculation Science, Engineering Drawing and Employability Skills) impart requisite core skill,knowledge and life skills.

After passing out the training program, the trainee is awarded National Trade Certificate(NTC) by DGT which is recognized worldwide.

Learning OutCome(In Two Year of DM Trade What should Trainee Learn

Construct different Geometric figures using Drawing Instruments following safety precautions.

Draw orthographic Projections given proper dimensioning with title block and heading using appropriate line type ans scale.

Construct free hand sketches of simple machine parts with correct proporations.

Consleadtruct plain scale,comparative scale, diagonal scale and vernier scale.

Draw sectional views showing orthographic projection.

Develop surface and interpenetration of solid in orthographic projection

Draw isometric projection from orthographic views (and vice-versa) and draw oblique projection from orthographic views

Draw and indicate the specification of different types of fastens, welds and locking devices as per SP-46:2003

Acquire basic knowledge on tools and euipment of Ailled trades viz. Fitter, Turner, Machinist, Sheet Metal Worker,Welder, Foundry man, Electrician and Maintenance Motor Vehicles.

Construct different types of gears, coupling and bearing with tolerance dimension and indicating surface finish symbol.

perform Computer application and Create 2D objetcs on CAD drawing space using commands from ribbon,menu bar, toolbars and by typing in command prompt.

In Second Year Trainee Learns Following Topics

Construct projection views of geometrical figureswith dimension and annotation on CAD in model space and viewpoint in layout space.

Draw in CAD detail and assembly drawing of machine parts viz. Pulleys, Pipe fitting, Gears and Cams applying range of congnitive and practical skills.

Construct drawing of engine parts with deatiled and assembly in template layout applying quality concept in CAD.

Create 3D solid by switching to 3D modeling workspace in CAD, generate views, Print Preview and Plotting.

Construct detailed and assembled drawing applying conventional sign & symbols using CAD

Prepare drawing of machine part by measuring with measuring instruments

Draw a machine a shop layout considering process path and ergomics(human facotr)

Create and plot assembly and detail views of machine part with DImensions, Annotations, Title Block and Bill of materials in Solid Works/AutoCAD Inventor/ 3D Modeling.

Create production drawing of machine part.

Draughtsman Mechanic Course Details

Name of the Trade Draughtsman Mechanic
NSQF Level Level 5
Duration of Craftsman Training 2 Year
Entry Qualification 10th passed with Science & Mathematics or it's Equilavant

Draughtsman Mechanic Course Structure

Sr.No Course Element Notational hours
1st year 2 nd Year
1 Professional Skill(Trade Practical) 1120 1120
2 Professional Skill(Trade Theory) 240 320
3 Workshop Calculation & Science 80 80
4 Employability Skills 160 80
Total 1600 1600

Job Opportunity After DM Trade

progress further as Senior Technician, Supervisor and can rise up to the level of Manager.

Can become Entrepreneur in the related field.

Can appear in 10+2 examinaton through National Institute of Open Schooling(NIOS) for acquiring higher secondary certificate and can go further for General/ Technical education.

Can take admission in diploma course in notified branches of Engineering by lateral entry

Can join Apprenticeship programme in different types of industries leading to National Apprenticeship certificate (NAC).
